| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Application | Suitable For Highways, Flyovers, And Bridge Deck Expansion Gaps |
| Function | Accommodates Structural Movement In Bridge Decks |
| Click to view more | |
Product Details
Movement Capacity
Typically Up To 40-50 Mm
Construction Type
Elastomeric Slab Seal System Embedded Between Steel Edge Angles Or Concrete Nosing
Seal Material
High-grade Elastomeric Rubber (Neoprene / EPDM Based Compounds)
Edge Support
Steel Angle Or Reinforced Concrete Edge Beams For Load Distribution
Waterproofing
Provides Effective Sealing Against Water Leakage Into Substructure
Anchorage System
Embedded Anchorage System Fixed Into Bridge Deck Concrete
Traffic Performance
Designed For Smooth Vehicular Movement With Minimal Vibration And Noise
We are a leading manufacturer, exporter, and supplier of high-quality Slab Seal Expansion Joints originating from India. Our elastomeric slab seal system is ideal for highways, accommodating structural movement in bridge decks up to 40-50 mm. Constructed with high-grade elastomeric rubber, typically Neoprene or EPDM based compounds, and supported by steel angles or reinforced concrete edge beams, our product ensures effective waterproofing and smooth vehicular movement with minimal vibration and noise. The embedded anchorage system fixed into bridge deck concrete provides reliable support for traffic performance, making it a top choice for infrastructure projects.
Specification
| Sr No. | Test | Unit | Specification and Testing Method | Specimens |
| 1 | Hardness | IRHD | IS: 3400 (Part II) Cl.5.1.2.2 | 4.0mm (min ) thickness of Test specimen |
| 2 | Tensile Strength | MPa | IS:3400 ( Part I) | Thick- 2.0 +.0.20mm |
| 3 | Elongation at Break | % | Table 1 Type -1 | Width 6.0 + 0.40mm Bench Mark-25..0mm(max) |
| 4 | Adhesion Strength (Metal to Rubber | KN/M | IS:3400 ( Part XIV) Cl.3.3 | Length -125mm Width-25mm Width-25mm 1 g (min) |
| 5 | Ash Content | % | IS:3400 (Part XXII) | 1 g (min) |
| 6 | Polymer Identification | Chemically | Cl. A-8.3.1 IS | 0.5 g (min) |
| 7 | Percentage of Polymers | % | IS | 1 g (min) |
| 8 | Compression Set | % | IS: 3400 (Part X) Cl. 5.1 | Thick -12.5 + 0.50mm Dia-29 + 0.50mm |
